Chemical Oil Drilling CMC Polymer Polyanionic Cellulose PAC HV

Chemical Oil Drilling CMC Polymer Polyanionic Cellulose PAC HV
Chemical Oil Drilling CMC Polymer Polyanionic Cellulose PAC HV

Large Image :  Chemical Oil Drilling CMC Polymer Polyanionic Cellulose PAC HV

Product Details:
Place of Origin: China
Brand Name: Fuxin
Certification: ISO9001:2008, ISO22000:2005, QS, HALAL, KOSHER, HACCP, FDA certificates.
Model Number: PAC HV, PAC LV, PAC R
Payment & Shipping Terms:
Minimum Order Quantity: 1 MT
Price: Negotiate
Packaging Details: 25kgs/bag, customized available
Delivery Time: 5-20 work days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20,000 MT/ Year
Detailed Product Description
Classification: Chemical Auxiliary Agent MF: [C6H7O2(OH)2CH2COONa]n
CAS No.: 9004-32-4 HS Code: 3912310000
Place Of Origin: Foshan, Guangdong, China Raw Material: Refine Cotton
Appearance: White Or Yellowish Fine Powder Or Granule, Brown Color Available Degree Of Substitution: ≥0.9, Ultra High DS >2.3 Available
Solubility: Cold Or Hot Water Available Function: Thickener, Stabilizer, Emulsifier, Water Retainer, Suspension, DISPERSANT AGENT
Highlight:

Chemical Oil Drilling CMC

,

Oil Drilling CMC Polymer

,

PAC HV

Polyanionic Cellulose Polymer PAC LV R HV Oil Drilling Fluid Mud





FUXIN® PAC & CMC can be used in drilling fluid, fixing fluid and fracturing fluid. In drilling fluid, it works as viscosifier, filtration reducer, and rheology controller; in fixing fluid, it is used to control fluid viscosity, suspend heavy objects, and avoid fluid loss; in fracturing fluid, it is used to carry stuffing and avoid fluid loss. And PAC also used as a thickener for low-density brines, as rheology modifier.

Instant products, like the granular PAC, used in severe environment, it will be more convenient and simpler, and it will be more effective in mud allocating.



Applications in Fresh Water, Sea Water and Saturated Water
1. Improves filtercake lubricity.
2. Stabilizes fluid rheology.
3. Cost effective, small usage, high yield.
4. Excellent salt tolerance and anti-bacteria property, convenient to use.
5. Outstanding API filtration control and suspending ability. Improve the viscosity significantly.
6. Environment friendly





Applications in Drilling Fluid
1. Protect the wall of oil well, prevent mud flowing away and carry crumbs.
2. Protect drilling bit and increase drilling speed.
3. In low solid or none solid drilling fluid, it can reduce the fluid loss and the thickness of the mud cake obviously.
4. Strong inhibition effect to shale swelling and disintegration.





Applications in Fixing Fluid
1. Protect the wall of the oil well, stop the fluid entering into the pores or cracks.
2. Control the fluid viscosity, heavy object suspension, and prevent fluid loss.

When CMC is used in fracturing fluid, it can bring ‘stuffing’ into the cracks of oil well in high efficiency and establish osmosis channel, which can effectively prevent fluid entering into oil well structure, reduce fluid loss, and lower the pressure.
The ultra high viscosity products can replace guar gum, reduce the production cost.





HV-CMC, LV-CMC
Technical Specifications of HV-CMC, LV-CMC
Specifications Performance Test
Items 指标

In distilled water

In salt water

In saturated water

Base Mud
Filtration (ml) 60±10 90±10 100±10
Apparent Viscosity (CPS) ≤6 ≤6 ≤10
pH 8.0 ± 1.0 8.0 ± 1.0 7.5 ± 1.0
HV-CMC Yield of 15CPS (m3/t) ≥160 ≥130 ≥140
LV-CMC 10ml Filtration: 10ml/h Addition (g/l) / ≤7.0 ≤10.0

Apparent Viscosity (CPS)
/ ≤4 ≤6
Remarks HV-CMCOCMA DFCP-7; LV-CMCOCMA DFCP-2.
The performance test of HV-CMC as per OCMA DFCP-7 methods.
The performance test of LV-CMC as per OCMA DFCP-2 methods.





CMC-HVT, CMC-LVT
Technical Specifications of CMC-HVT, CMC-LVT
Type 600r/min
Viscometer dial reading at 600r/min.
Filtration (ml)
In distilled water 40g/L
In 40g/L salt water

In saturated salt water
CMC-HVT ≥30 ≥30 ≥30 ≤10
CMC-LVT ≤90 / / ≤10
Remarks API13A.Conforms to API Spec. 13A test methods





CMC Technical Specifications of CMC for Fracturing Fluid
Type Viscosity (mPa.s) pH (D.S.)
Degree of Substitution
Loss on Drying (%) Purity(%)
Min. Max.
Concentration



Min.



Max.

CMC9-5000 5000 6000 1% 6.5-9.0 0.90 / ≤10.0 ≥99
CMC9-6000 6000 7000 1% 6.5-9.0 0.90 / ≤10.0 ≥99
CMC9-7000 7000 8000 1% 6.5-9.0 0.90 / ≤10.0 ≥99





PAC

Technical Specifications of PAC for Drilling Fluid

TYPE Apparent Viscosity (mPa•s) Filtration (ml) pH (D.S.)
Degree of Substitution
Loss on Drying (%)
Purity (%)
Min.
Max.
Min.
Max.
PAC-LVT1 / 30 ≤16 6.5-9.0 0.90 / ≤9 ≥65
PAC-LVT2 / 30 ≤14 6.5-9.0 0.90 / ≤9 ≥75
PAC-LV / 30 ≤13 6.5-9.0 0.90 / ≤9 ≥85
PAC-LV1 / 40 ≤12 6.5-9.0 0.90 / ≤9 ≥95
PAC-LVG
(Granule)
/ 40 ≤12 6.5-9.0 0.90 / ≤9 ≥95
PAC-R 35 / ≤23 6.5-9.0 0.90 / ≤9 ≥75
PAC-HV 50 / ≤23 6.5-9.0 0.90 / ≤9 ≥85
PAC-HV1 50 / ≤20 6.5-9.0 0.90 / ≤9 ≥95
PAC-HVG
(Granule)
60 / ≤18 6.5-9.0 0.90 / ≤9 ≥95
