Home ProductsOil Drilling CMC

Powder PAC-R Oil drilling fluid Polyanionic Cellulose Polymer Additives

Certification
china Fushixin Polymer Fiber (Foshan) Co., Ltd. certification
china Fushixin Polymer Fiber (Foshan) Co., Ltd. certification
I'm Online Chat Now

Powder PAC-R Oil drilling fluid Polyanionic Cellulose Polymer Additives

Powder PAC-R Oil drilling fluid Polyanionic Cellulose Polymer Additives
Powder PAC-R Oil drilling fluid Polyanionic Cellulose Polymer Additives

Large Image :  Powder PAC-R Oil drilling fluid Polyanionic Cellulose Polymer Additives

Product Details:
Place of Origin: China
Brand Name: Fuxin
Certification: ISO9001:2008, ISO22000:2005, QS, HALAL, KOSHER, HACCP, FDA certificates.
Model Number: PAC HV, PAC LV, PAC R
Payment & Shipping Terms:
Minimum Order Quantity: 1 MT
Price: Negotiate
Packaging Details: 25kgs/bag, customized available
Delivery Time: 5-20 work days
Payment Terms: T/T, L/C, Western Union, MoneyGram
Supply Ability: 20,000 MT/ Year
Detailed Product Description
Model NO.: Pac Lv Drilling Fluid Mud Environmental Protection: Yes
Color: White Appearance: White Or Yellowish Fine Powder Or Granule, Brown Color Available
Kind: Mud Additives Application: Fluid Loss Control Additive
Standard: API 13A, ISO, Ocma Standard Trademark: Fuxin
Transport Package: Kraft Paper Bag, Customize Available Specification: Net Weight: 25kg/bag.
Origin: Foshan, Guangdong, China HS Code: 3912310000
Port: Foshan, China Classification: Chemical Auxiliary Agent
MF: [C6H7O2(OH)2CH2COONa]n CAS No.: 9004-32-4
Place Of Origin: Foshan, Guangdong, China Raw Material: Refine Cotton
Degree Of Substitution: ≥0.9, Ultra High DS >2.3 Available Solubility: Cold Or Hot Water Available
Function: Thickener, Stabilizer, Emulsifier, Water Retainer, Suspension, DISPERSANT AGENT
Highlight:

Powder PAC-R

,

PAC-R

,

Polyanionic Cellulose Polymer Additives

Product Description

Poly Anionic Cellulose Polymer PAC-LV /PAC- HV / PAC-R
 for Oil Refining Drilling Fluid Mud

FUXIN® PAC & CMC can be used in drilling fluid, fixing fluid and fracturing fluid. In drilling fluid, it works as viscosifier, filtration reducer, and rheology controller; in fixing fluid, it is used to control fluid viscosity, suspend heavy objects, and avoid fluid loss; in fracturing fluid, it is used to carry stuffing and avoid fluid loss. And PAC also used as a thickener for low-density brines, as rheology modifier.

Instant products, like the granular PAC, used in severe environment, it will be more convenient and simpler, and it will be more effective in mud allocating.

Polyanionic Cellulose Product Description

Technical Specifications of PAC for Drilling Fluid
TYPE  Apparent Viscosity (mPa•s) Filtration (ml) pH (D.S.)
Degree of  Substitution
Loss on Drying (%) Purity (%)
Min. Max. Min. Max.
PAC-LVT1 / 30 ≤16 6.5-9.0 0.90  / ≤9 ≥65
PAC-LVT2 / 30 ≤14 6.5-9.0 0.90  / ≤9 ≥75
PAC-LV / 30 ≤13 6.5-9.0 0.90  / ≤9 ≥85
PAC-LV1 / 40 ≤12 6.5-9.0 0.90  / ≤9 ≥95
PAC-LVG
(Granule)
/ 40 ≤12 6.5-9.0 0.90  / ≤9 ≥95
PAC-R 35 / ≤23 6.5-9.0 0.90  / ≤9 ≥75
PAC-HV 50 / ≤23 6.5-9.0 0.90  / ≤9 ≥85
PAC-HV1 50 / ≤20 6.5-9.0 0.90  / ≤9 ≥95
PAC-HVG
(Granule)
60 / ≤18 6.5-9.0 0.90  / ≤9 ≥95

Technical Specifications of HV-CMC, LV-CMC
Specifications Performance Test
Items Indicators
In distilled water In salt water In saturated water
Base Mud Filtration (ml) 60±10 90±10 100±10
Apparent Viscosity (CPS) ≤6 ≤6 ≤10
PH 8.0 ± 1.0 8.0 ± 1.0 7.5 ± 1.0
HV-CMC Yield of 15CPS (m3/t) ≥160 ≥130 ≥140
LV-CMC Filtration:10ml/h Addition (g/l) / ≤7.0 ≤10.0
Apparent Viscosity (CPS) / ≤4 ≤6
Remarks The performance test of HV-CMC as per OCMA DFCP-7 methods.
The performance test of LV-CMC as per OCMA DFCP-2 methods.


Technical Specifications of CMC-HVT, CMC-LVT
Type Viscometer dial reading at 600r/min. Filtration (ml)
In distilled water In 40g/L salt water In saturated salt water
CMC-HVT ≥30 ≥30 ≥30 ≤10
CMC-LVT ≤90 / / ≤10
Remarks Conforms to API Spec.13A test methods
*Kindly contact us for specification and information about any specific grade of CMC other than mentioned in the above table.

Applications in Fresh Water, Sea Water and Saturated Water
1.Improves filtercake lubricity.
2.Stabilizes fluid rheology.
3.Cost effective, small usage, high yield.
4.Excellent salt tolerance and anti-bacteria property, convenient to use.
5.Outstanding API filtration control and suspending ability.Improve the viscosity significantly.
6.Environment friendly

Applications in Drilling Fluid
1.Protect the wall of oil well, prevent mud flowing away and carry crumbs.
2.Protect drilling bit and increase drilling speed.
3.In low solid or none solid drilling fluid, it can reduce the fluid loss and the thickness of the mud cake obviously.
4.Strong inhibition effect to shale swelling and disintegration.

Applications in Fixing Fluid
1.Protect the wall of the oil well, stop the fluid entering into the pores or cracks.
2.Control the fluid viscosity, heavy object suspension, and prevent fluid loss.

When CMC is used in fracturing fluid, it can bring 'stuffing' into the cracks of oil well in high efficiency and establish osmosis channel, which can effectively prevent fluid entering into oil well structure, reduce fluid loss, and lower the pressure.
The ultra high viscosity products can replace guar gum, reduce the production cost.

Sales Record of Oil drilling grade CMC



Intertek Test Report for CMC



Packaging & Delivery:

Packaging Details:
1) 25kgs per kraft paper bag, inner PE bag
2) Jumbo bag
3) Palletized, customized available
4)17-20 tons for one 20' FCL.

Delivery Detail:
Shipped in 7-15 days after payment



Company Information:



Fushixin Polymer Fiber (Foshan) Co., Ltd. was established in 2002, locates in Nanhai, Foshan, Guangdong, is a high-tech enterprise which intergrates the research, production and application of CMC (Sodium Carboxymethyl Cellulose), PAC (Polyanionic Cellulose), CMS (Carboxymehtyl Starch) and other cellulose ethers.

Fushixin Polymer Fiber (Foshan) Co., Ltd. has a powerful processing ability of cellulose, develops and utilizes new technology to explore more market opportunities, takes advantage of the integral superiority of modern chemical industry, adopts the latest technology, materials and equipments. Our company is qualified with ISO9001:2008, ISO22000:2005, QS, HALAL, KOSHER, HACCP, FDA ertificates.

The application of our products covers ceramics, oil drilling, fracturing, food, toothpaste, detergent, mining, papermaking, textile printing and dyeing, building materials, battery, welding, etc. We produce the cellulose powder or granulated available, from ultra low viscosity to ultra high viscosity, purity can achieve above 99.5%. All our products live up to the international test and quality standards.

As a trustable and reliable partner, FUSHIXIN is a well known proverbial company in both domestic and international markets. We have established business relations with several hundreds of companies in China and abroad, set up offices in Vietnam and Thailand. Our products have been exported to Southeast Asia, South Asia, Middle East, Middle Asia, Africa, Australia, Europe, America, etc.



Exhibition and Customers Visit Photos:

As one of the biggest manufacturers of CMC (sodium carboxymethyl cellulose) and PAC (Polyanionic cellulose), Fushixin is active in the domestic and foreign market.



 F&Q:
Q: Are you trading company or manufacturer ?

A: We are factory. Welcome to visit our plant in your convenient time.

Q: How long is your delivery time ?

A: Generally it is 2-7 days if the cargo is in stock, or 15-20 days if the goods are not in stock. It is according to quantity.

Q: Do you provide samples ?

A: Yes, free trial package of 0.5 kg sample. Please send us an email describing your usage plan. Free sample is for manufacture only and not for R&D purpose.

Q: What is your terms of payment ?

A: 30% T/T in advance , balance against scan copy of B/L. L/C acceptable.
